Default Lego = Llama's ultimate working material

Now that I'm finally done some random sketches that I think almost look like some sort of concept designs for certain areas, and have actually start working, albeit slowly, on the CAD design, I figured it's time to unveil my upcoming project!

Leper Llama's Lego Rig! (God, I'm sorry, I couldn't think of a word that started with L that means rig)

The idea is to build a case completely out of Lego, and in the end, use as little non-Lego parts as possible. It's also meant to encompass everything from my PSU to my water cooling parts, so basically, other then a few things here and there, it's being built around the parts.

The case is being designed with a tower mindset, and will also include a window on the side of the case. Currently the plan is to keep the case completely black, other then a few select areas.

While the case itself won't be built probably for another month yet, due to the fact I'm hoping to move on the 31st, and it's not worth lugging around the parts (as well as I need to watch my money for the first month-ish), I'm hoping to have the CAD design completely finished, minus fine tuning before I leave.

"But Llama, why, why would you want to spend so much on building a case out of Lego when you can buy a really good one for the same price!"

Why, I'm glad you asked anonymous! While true, this project is going to cost a fair bit of change, and could easily be hitting $200 by the time the project is complete, but on the other hand, it gives the joy of having a case that no one else has. As well as a computer based around your requirements. Also, the great thing with Lego is, if you need to adapt due to new parts, all you need to do is take things apart and set it up however you need to!

Augest 14th/08
Now, for some teaser pictures! Currently I only have the base as well as the beginnings of the PSU caddy designed. This took me quite a bit of work to figure out, as I wanted to keep the PSU on the bottom, but yet, be able to take it out without ripping apart half the case. So, with a bit [read; many apon many] alterations to a basic diagram, I've managed to come up with a way that will allow me to place the PSU into a caddy, and lock it into place.

Anywho, onto the pictures!


This here is the basic base of the case. Yes, I know, it's bare currently, but she's what holds everything together!


This is the starting of the PSU caddy I speak of, I hope to have it (along with the screw in's) completely designed in a day or two


Ah, now you can stop asking yourself "Wtf, how will that work". As you can see, it will just slide into place, and allow me to lock it into place!
__________________
Seriously people, I am not a mod. Stop messaging me D:
